7 layers – market leader in Bluetooth® qualification

BQTF (Bluetooth® Qualification Test Facility)
7 layers laboratories have BQTF status, thus being able to test the growing number of Bluetooth® category “A” test cases for qualification testing.

BQB (Bluetooth® Qualification Body)
7 layers has 5 experienced BQB’s worldwide who lead you smoothly through the qualification process and help you get your products listed on the “Qualified Products List”.

Test Services
7 layers offers full scope Bluetooth® testing in laboratories, organized via the
InterLab® system.

Qualification testing

  • Radio Conformance testing (on TS 8960)

  • Protocol and Profile testing
    on PTW60     for core specification 1.1 and on PTW70 for 1.2

  • Profile Interoperability testing:
    Our Interoperability lab covers Bluetooth    ® end-user products, Profile Interoperability testers (PITS), Bluetooth® applications and Bluetooth® modules and chipsets.

Regulatory type approval testing

  • Testing according to FCC part 15 and EN 300328-2

  • EMC testing according to EN 301489-17

  • SAR, UL, Safety

Type approval services
Thanks to the regularly updated information from our large data base and our highly experienced engineers, type approval at 7 layers is easy and non bureaucratic.


Setting-up Bluetooth® test laboratories
7 layers offers various methods of setting up, controlling, maintaining and supporting Bluetooth® test laboratories via our InterLab® system. InterLab® laboratories can be established for a single test set-up as well as for complete Bluetooth® qualification test laboratories.
More information: Click on “InterLab” in head of menu

Script Engine
The ready to use InterLab® Protocol Script Engine for Bluetooth® provides a cost effective solution for Bluetooth® testing. It is an add-on to the PTW 60, offering you complete control over the instrument via a user-friendly graphical interface running on a standard personal computer. Combining the PTW 60 with the InterLab® script engine means, that developers can easily implement their own customized test cases. Such test cases can go above and beyond those for the Bluetooth® Qualification program, allowing a simple method of thoroughly testing in any conceivable way.

Reference Design testing and Fast Track Qualification
Thanks to the structure of the InterLab® system, 7 layers can offer highly efficient services in this sector. If manufacturers have their components or reference designs tested and qualified at a 7 layers BQTF, 7 layers then provides the results via InterLab® to other InterLab® laboratories if required. This information is then readily available for test projects of end-user products, which can be optimized thanks to the available information. Afterwards 7 layers takes care of all updates concerning components and reference designs. This way component and reference design manufacturers can offer their clients a unique service which will help them to get their products through the qualification process as fast and as easy as possible.
More information: Click on “InterLab” in head of menu

Experience

  • 7 layers has qualified and tested Bluetooth® products since the early days of this outstanding technology

  • We contributed to the test specification development

  • We are a leading developer of test cases and test systems for the core specification 2.0

  • We do extensive validation work
